Technical specifications
|
Model: |
Nexus 125 |
Years: |
2006-08 |
Engine:
|
Four stroke, single cylinder, SOHC, 4 valve
|
Capacity:
|
124 cc / 7.6 cu-in
|
Bore x Stroke:
|
57 x 48.6 mm
|
Cooling System:
|
Liquid cooled
|
Compression Ratio:
|
12.0:1
|
Induction:
|
RON 95 unleaded petrol
|
Ignition:
|
Electronic CDI
|
Starting:
|
Electric
|
Max Power:
|
14,5 hp / 10,7 kW @ 9750 rpm
|
Max Torque:
|
11,7 Nm / 8.6 lb-ft @ 8000 rpm
|
Transmission:
|
Twist-and-go CVT
|
Final Drive:
|
Belt
|
Frame:
|
Double cradle trellis made of high-strength steel tubes
|
Front Suspension:
|
Telescopic hydraulic fork with f 35 mm shafts; 94 mm wheel travel
|
Rear Suspension:
|
Double hydraulic shock absorber with four-position spring preload; 76 mm wheel travel
|
Front Brakes:
|
Single 260mm disc
|
Rear Brakes:
|
Single 240 disc
|
Front Tyre:
|
120/70-14
|
Rear Tyre:
|
140/60-14
|
Wheelbase:
|
1,530 mm / 60.2 in
|
Seat Height:
|
810 mm / 31.9 in
|
Dry Weight:
|
174.0 kg / 383.6 lbs
|
Wet Weight:
|
186.0 kg / 410.1 lbs
|
Fuel Capacity:
|
15 Litres / 3.9 US gal
|
