Technical specifications
|
| Model: |
CX 125 |
| Years: |
1991- |
|
Engine:
|
Two stroke, single cylinder, power valve
|
|
Capacity:
|
124 cc / 7.6 cu-in
|
|
Bore x Stroke:
|
56 x 50..5 mm
|
|
Cooling System:
|
Liquid cooled
|
|
Compression Ratio:
|
12.5:1
|
|
Induction:
|
32mm Dell'Orto VHSA32AS
|
|
Ignition:
|
CDI
|
|
Starting:
|
Electric
|
|
Max Power:
|
29.3 hp / 21.8 kW @ 9900 rpm
|
|
Max Torque:
|
18 Nm / 13.2 lb-ft @ 10250 rpm
|
|
Transmission:
|
6 Speed
|
|
Final Drive:
|
Chain
|
|
Front Suspension:
|
45mm Paioli forks, 100 wheel travel
|
|
Rear Suspension:
|
Single swinging arm
|
|
Front Brakes:
|
Single 300mm disc
|
|
Rear Brakes:
|
Single 240mm disc
|
|
Front Tyre:
|
120/60 -17
|
|
Rear Tyre:
|
150/60 -17
|
|
Dry Weight:
|
125.0 kg / 275 lbs
|
|
Fuel Capacity:
|
12 Litres / 3.17 US gal
|
|
Consumption Average:
|
16.8 km/lit
|
|
Braking 60 - 0 / 100 - 0:
|
13.0 m / 38.3 m
|
|
Standing ¼ Mile:
|
14.8 sec / 142.5 km/h
|
|
Top Speed:
|
168.3 km/h / 104.5 mph
|
