Technical specifications
|
| Model: |
Crono 125 |
| Years: |
1990- |
|
Engine:
|
Two stroke, single cylinder, power valve
|
|
Capacity:
|
124 cc / 7.6 cu-in
|
|
Bore x Stroke:
|
56 x 50.5 mm
|
|
Cooling System:
|
Liquid cooled
|
|
Compression Ratio:
|
12.5;1
|
|
Induction:
|
32mm Dell'Orto VHSA32ES
|
|
Ignition:
|
CDI
|
|
Starting:
|
Electric
|
|
Max Power:
|
29.3 hp / 21.8 kW @ 9900 rpm
|
|
Max Torque:
|
18 Nm / 13.2 lb-ft @ 10250 rpm
|
|
Transmission:
|
6 Speed
|
|
Final Drive:
|
Chain
|
|
Front Suspension:
|
40mm Telescopic Upside-down forks
|
|
Rear Suspension:
|
Vertical single shock
|
|
Front Brakes:
|
Single 300mm disc 2 [piston caliper
|
|
Rear Brakes:
|
Single 240mm disc 2 [piston caliper
|
|
Front Tyre:
|
100/80 -16
|
|
Rear Tyre:
|
130/70 -17
|
|
Dry Weight:
|
118 kg / 4.7 lbs
|
|
Fuel Capacity:
|
13 Litres / 3.4 US gal
|
|
Consumption Average:
|
15.7 km/lit
|
|
Braking 60 - 0 / 100 - 0:
|
12.6 m / 38.0 m
|
|
Standing ¼ Mile:
|
14.71 sec / 143.8 km/h
|
|
Top Speed:
|
172.3 km/h / 107 mph
|
