Ducati XDiavel Black Star (2021) technical specifications

Ducati XDiavel Black Star is produced in 2021. Engine is Four stroke, Testastretta DVT (Desmodromic Variable Timing), 90° L-Twin, 4 Desmodromically actuated valves per cylinder, dual spark, displacement 1262 cc / 77 cu in Ducati XDiavel Black Star weighs 221 kg / 487 lbs. Ducati XDiavel Black Star has 5 photos.

Technical specifications

+ Add to 'Compare list'

Model:	XDiavel Black Star
Years:	2021
Engine:	Four stroke, Testastretta DVT (Desmodromic Variable Timing), 90° L-Twin, 4 Desmodromically actuated valves per cylinder, dual spark
Capacity:	1262 cc / 77 cu in
Bore x Stroke:	106 x 71.5 mm
Cooling System:	Liquid cooled
Compression Ratio:	13.0:1
Exhaust:	Stainless steel exhaust and muffler with dual oval exits, catalytic converter and 2 lambda probes
Induction:	Electronic fuel injection system, 56mm elliptical throttle bodies full with ride-by-wire system
Emission:	Euro 5
Ignition:	Electronic
Starting:	Electric
Max Power Euro5:	118 kW / 160 hp @ 9500 rpm
Max Torque Euro5:	127 Nm / 93.7 lb-ft @ 5000 rpm
Clutch:	Slipper and self-servo wet multiplate clutch with hydraulic control
Transmission:	6-Speed
Final Drive:	Belt, front sprocket Z28, rear sprocket Z80
Primary Drive:	Straight cut gears, 1.84:1 ratio
Gear Ratios:	1st 37:15 / 2nd 30:17 / 3rd 27:20 / 4th 24:22 / 5th 23:24 / 6th 22:25
Frame:	Tubular steel trellis frame
Front Suspension:	50mm USD adjustable forks with DLC treatment
Front Wheel Travel:	120 mm / 4.7 in
Rear Suspension:	Single shock absorber, adjustable preload and rebound, remote reservoir, Single sided cast/trellis frame swingarm
Rear Wheel Travel:	110 mm / 4.3 in
Front Brakes:	2x 320 mm semifloating discs, radial Brembo monobloc 4-piston M50 callipers, PR16/19 radial master cylinder
Rear Brakes:	Single 265 mm disc, Brembo 2-piston floating calliper
ABS:	BOSCH cornering ABS as standard equipment
Front Wheel:	Forged aluminum, 3.50 x 17
Rear Wheel:	Forged aluminum, 8.00 x 17
Front Tyre:	120/70 ZR17 Pirelli Diablo Rosso III
Rear Tyre:	240/45 ZR17 Pirelli Diablo Rosso III
Rake:	30º
Trail:	130 mm / 5.1 in
Wheelbase:	1615 mm / 63.6 in
Seat Height:	755 mm / 29.7 in
Dry Weight:	221 kg / 487 lbs
Wet Weight:	247 kg / 544 lbs
Fuel Capacity:	18 L / 4.75 US gal
