Ducati Scrambler 1100 Special (2018) technical specifications

Ducati Scrambler 1100 Special is produced in 2018. Engine is Four stroke, L-Twin, Desmodromic distribution, 2 valves per cylinder, displacement 1079 cc / 65.8 cu-in , produces power 84.5hp / 63 kW @ 7500 rpm and 65 lb-ft / 88 Nm @ 4750 rpm. Ducati Scrambler 1100 Special weighs 194 kg / 428 lb. Ducati Scrambler 1100 Special has 6 photos.

Technical specifications

+ Add to 'Compare list'

Model:	Scrambler 1100 Special
Years:	2018
Engine:	Four stroke, L-Twin, Desmodromic distribution, 2 valves per cylinder
Capacity:	1079 cc / 65.8 cu-in
Bore x Stroke:	98 x 71 mm
Cooling System:	Air/oil cooled
Compression Ratio:	11.0:1
Induction:	Electronic fuel injection, Ø55 mm throttle body with full Ride by Wire (RbW)
Ignition:	Marelli electronic
Starting:	Electric
Exhaust:	2-1-2 system with catalytic converter and 2 lambda probes, twin stainless steel muffler with aluminium covers and end caps
Max Power:	84.5hp / 63 kW @ 7500 rpm
Max Torque:	65 lb-ft / 88 Nm @ 4750 rpm
Clutch:	Light action, wet, multi-plate clutch with hydraulic control. Self-servo action on drive, slipper action on over-run
Transmission:	6 Speed
Final Drive:	Chain, front sprocket 15; rear sprocket 39
Primary Drive:	Straight cut gears; Ratio 1.85:1
Gear Ratio:	1=37/15 2=30/17 3=28/20 4=26/22 5=24/23 6=23/24
Frame:	Tubular steel trellis frame
Front Suspension:	Marzocchi fully adjustable Ø45 mm USD fork
Front Wheel Travel:	150 mm / 5.9 in
Rear Suspension:	Kayaba monoshock, pre-load and rebound adjustable
Rear Wheel Travel:	150 mm / 5.9 in
Front Brakes:	2 x 320 mm semi-floating discs, radially mounted Brembo Monobloc M4.32 callipers, 4-piston, axial pump with Bosch Cornering ABS as standard equipment
Rear Brakes:	245 mm disc, 1-piston floating calliper with Bosch Cornering ABS as standard equipment
Front Wheel:	Spoked aluminium wheel, 3.50" x 18"
Rear Wheel:	Spoked aluminium wheel, 5.50" x 17"
Front Tyre:	Pirelli MT 60 RS 120/80 ZR18
Rear Tyre:	Pirelli MT 60 RS 180/55 ZR17
Rake:	24.5°
Trail:	111 mm / 4.4 in
Total steering lock:	34°
Dimensions:	Length 2190 mm / 86.0 in Height 1330 mm / 52.4 in Width 920 mm / 36.2 in
Wheelbase:	1514 mm / 59.6 in
Seat Height:	810 mm / 31.9 in
Dry Weight:	194 kg / 428 lb
Wet Weight:	211 kg / 465 lb
Fuel Capacity:	15 Litres / 3.96 US gal
