Ducati Multistrada V4 RS (2024) technical specifications

Ducati Multistrada V4 RS is produced in 2024. Engine is Four stroke, Desmosedici Stradale 90? V4, counter-rotating crankshaft, 4 Desmodromic timing, 4 valves per cylinder, twin-pulse firing order, displacement 1103 cc / 67.3 cu in , produces power 132 kW / 180 hp @ 12250 rpm and 118 Nm / 87 lb-ft @ 9500 rpm. Ducati Multistrada V4 RS weighs . Ducati Multistrada V4 RS has 8 photos.

Technical specifications

+ Add to 'Compare list'

Model:	Multistrada V4 RS
Years:	2024
Engine:	Four stroke, Desmosedici Stradale 90? V4, counter-rotating crankshaft, 4 Desmodromic timing, 4 valves per cylinder, twin-pulse firing order
Capacity:	1103 cc / 67.3 cu in
Bore x Stroke:	81 x 53.5 mm
Compression Ratio:	14.0:1
Cooling System:	Liquid cooled
Induction:	Electronic fuel injection system. Twin injectors per cylinder. Full ride-by-wire elliptical throttle bodies
Emission:	EURO5+
Exhaust:	Stainless steel pr-silencer, double catalytic converter and 8 Lambda probes. Akrapovic titanium muffler
Starting:	Electric
Max Power:	132 kW / 180 hp @ 12250 rpm
Max Torque:	118 Nm / 87 lb-ft @ 9500 rpm
Clutch:	Multi-plate dry clutch with slipper action on over-run
Transmission:	6 Speed with Ducati Quick Shift (DQS) up/down EVO 2
Primary Drive:	Straight cut gears, Ratio 1.80:1
Final drive:	Chain 525, Front sprocket Z15, Rear sprocket Z43
Gear Ratio:	1st 40/13 2nd 36/16 3rd 34/19 4th 31/21 5th 29/23 6th 27/25
Frame:	Aluminum monocoque frame
Front Suspension:	?hlins 48 mm fully adjustable fork with TiN treatment. Electronic compression and rebound damping adjustment with ?hlins Smart EC 2.0 event-based mode
Front Wheel Travel:	170 mm / 6.7 in
Rear Suspension:	Fully adjustable ?hlins TTX36 mono-shock unit. Electronic compression and rebound damping adjustment with ?hlins Smart EC 2.0 event-based mode, electronic pre-load adjusment, aluminium single-sided swingarm
Rear Wheel travel:	170 mm / 6.7 in
Front Brakes:	2 x 330 mm semi-floating discs, radially mounted Brembo Stylema monobloc 4-piston 2-pad callipers, radial master cylinder
Rear Brakes:	Single 265 mm disc, Brembo 2-piston floating calliper
ABS:	Bosch Cornering ABS EVO
Wheels:	5-split spoke carbon fiber
Front Rim:	3.50 x 17
Rear Rim:	6.00 x 17
Front Tyre:	120/70 ZR17 Pirelli Diablo Rosso Corsa
Rear Tyre:	190/55 ZR17 Pirelli Diablo Rosso Corsa
Rake:	25.75?
Trail:	120 mm / 4,74 in
Wheelbase:	1592 mm / 62.7 in
Seat Height:	Adjustable, 840 - 860 mm / 33.1 - 33.9 in Low seat: 810 - 830 mm / 31.9 - 32,7 in
Dry Weight:
Wet Weight:
Fuel Capacity:	22 Litres / 5.8 US gal
Safety Equipment:	Riding Modes, Power Modes, Bosch Cornering ABS EVO, Ducati Traction Control (DTC) EVO 2, Ducati Wheelie Control (DWC) Daytime running light, Ducati Cornering Light, Ducati Brake light, Vehicle hold control, radar system (Adaptive Cruise Control + Blind spot detection)
Standard Equipment:	?hlins Smart EC 2.0 electronic suspension, Ducati Quick Shift, Hands free, Backlit handlebar switches, 6.5" TFT colour display with Ducati Connect and full-map navigation system
