Ducati Multistrada 1260 (2020) technical specifications
Ducati Multistrada 1260 is produced in 2020. Engine is Four stroke, 90° “L” twin cylinders,Testastretta DVT with Desmodromic Variable Timing, DOHC, 4 valves per cylinder, displacement 1262 cc / 77.0 cu-in , produces power 156 hp / 116.2 kW @ 9500 rpm and 130 Nm / 96.2 lb-ft @ 7500 rpm. Ducati Multistrada 1260 weighs 209 kg / 461 lbs. Ducati Multistrada 1260 has 1 photos.
Technical specifications
+ Add to 'Compare list'| Model: | Multistrada 1260 |
| Years: | 2020 |
| Engine: | Four stroke, 90° “L” twin cylinders,Testastretta DVT with Desmodromic Variable Timing, DOHC, 4 valves per cylinder |
| Capacity: | 1262 cc / 77.0 cu-in |
| Bore x Stroke: | 106 x 71,5 mm |
| Cooling System: | Liquid cooled |
| Compression Ratio: | 13.0:1 |
| Lubrication: | Wet sump |
| Exhaust: | Stainless steel muffler with catalytic converter and 2 lambda probes, aluminium tail pipes |
| Induction: | Bosch electronic fuel injection system, elliptical throttle bodies with Ride-by-Wire, equivalent diameter 56 mm |
| Ignition: | Marelli electronic |
| Starting: | Electric |
| Max Power: | 156 hp / 116.2 kW @ 9500 rpm |
| Max Torque: | 130 Nm / 96.2 lb-ft @ 7500 rpm |
| Clutch: | Light action, wet, multiplate clutch with hydraulic control. Self-servo action on drive, slipper action on over-run |
| Transmission: | 6 Speed |
| Final Drive: | Chain; Front sprocket 15; Rear sprocket 40 |
| Primary Drive: | Straight cut gears; Ratio 1.84:1 |
| Gear Ratio: | 1=37/15 2=30/17 3=27/20 4=24/22 5=23/24 6=22/25 |
| Frame: | Tubular steel trellis frame |
| Front Suspension: | 48 mm fully adjustable USD forks. |
| Front Wheel Travel: | 170 mm / 6.7 in |
| Rear Suspension: | Fully adjustable Sachs monoshock unit. Remote spring preload adjustment. Aluminium single-sided swing-arm. |
| Rear Wheel Travel: | 170 mm / 6.7 in |
| Front Brakes: | 2 x 320 mm semi-floating discs, radially mounted monobloc Brembo callipers, 4-piston, 2-pad, with cornering ABS as standard equipment |
| Rear Brakes: | Single 265 mm disc, 2-piston floating calliper, with cornering ABS as standard equipment |
| Front Wheel: | 5-spoke Y-shape cast light alloy 3.50" x 17" |
| Rear Wheel: | 5-spoke Y-shaped cast light alloy 6.00" x 17" |
| Front Tyre: | 120/70 R17 Pirelli Scopion Trail II |
| Rear Tyre: | 190/55 R17 Pirelli Scorpion Trail II |
| Rake: | 24° |
| Trail: | 109 mm / 4.3 in |
| Wheelbase: | 1529 mm / 60.2 in |
| Seat Height: | Adjustable 825 mm / 32.5 in - 845 mm / 33.3 in |
| Dry Weight: | 209 kg / 461 lbs |
| Wet Weight: | 232 kg / 511 lbs |
| Fuel Capacity: | 20 Litres / 5.3 US gal / 4.4 Imp gal |
| Instrumentation: | LCD |
| Electronics: | 1260 model: Vehicle Hold Control (VHC), Riding Modes, Power Modes, Ducati Safety Pack (Bosch Cornering ABS + DTC), Ducati Wheelie Control (DWC), Cruise control, Hands-Free, Backlit handlebar switches, Auto-off indicators, ready for Ducati Quick Shift (DQS) up/down, Ducati Multimedia System (DMS), Anti-theft system. |
