Ducati Monster S2R 800 (2005) technical specifications
Ducati Monster S2R 800 is produced in 2005. Engine is Four stroke, 90° “L”t win cylinder, SOHC, desmodromic 2 valves per cylinder., displacement 803 cc / 49.0 cu in , produces power 56.7 kW / 77 hp @ 8250 rpm and 73 Nm / 7.4 kgf-m / 54 ft-lbs @ 6500 rpm. Ducati Monster S2R 800 top speed is 205.8 km/h / 127.9 mph. Ducati Monster S2R 800 weighs 179 kg / 395 lbs. Ducati Monster S2R 800 has 2 photos.
Technical specifications
+ Add to 'Compare list'| Model: | Monster S2R 800 |
| Years: | 2005 |
| Engine: | Four stroke, 90° “L”t win cylinder, SOHC, desmodromic 2 valves per cylinder. |
| Capacity: | 803 cc / 49.0 cu in |
| Bore x Stroke: | 88 x 66 mm |
| Compression Ratio: | 10.5:1 |
| Cooling System: | Air cooled |
| Induction: | Fuel injection, 45 mm throttle body |
| Exhaust: | 2-1-2, High |
| Emission: | Euro2 |
| Ignition: | Marelli electronic |
| Starting: | Electric |
| Max Power: | 56.7 kW / 77 hp @ 8250 rpm |
| Max Torque: | 73 Nm / 7.4 kgf-m / 54 ft-lbs @ 6500 rpm |
| Clutch: | APTC wet multiplate with hydraulic control |
| Transmission: | 6 Speed |
| Final Drive: | Chain; Front sprocket 15; Rear sprocket 42 |
| Primary Drive: | Straight cut gears; ratio 1.85 |
| Gear Ratio: | 1st 32/13, 2nd 30/18, 3rd 28/21, 4th 26/23, 5th 22/22, 6th 24/26 |
| Frame: | Tubular steel trellis |
| Front Suspension: | 43 mm Upside-down non adjustable forks |
| Front Wheel Travel: | 130 mm / 5.1 in |
| Rear Suspension: | Progressive linkage with fully adjustable Sachs monoshock with piggy back aluminum swing arm |
| Rear Wheel Travel: | 148 mm / 5.8 in |
| Front Brakes: | 2 x 300 mm Discs, 4 piston calipers |
| Rear Brakes: | Single 245 mm disc, 2 piston caliper |
| Front Tyre: | 120/70 - ZR17 |
| Rear Tyre: | 180/55 - ZR17 |
| Rake: | 24° |
| Wheelbase: | 1440 mm / 56.7 in |
| Dry Weight: | 179 kg / 395 lbs |
| Fuel Capacity: | 14 Litres / 3.6 US gal |
| Consumption Average: | 5.2 L/100 km / 19.1 km/l / 45 US mpg / 54 Imp mpg |
| Standing ¼ Mile: | 12.2 sec |
| Top Speed: | 205.8 km/h / 127.9 mph |
