Ducati Hypermotard 698 Mono / 698 Mono RVE (2024) technical specifications

Ducati Hypermotard 698 Mono / 698 Mono RVE is produced in 2024. Engine is Four stroke, Superquadro single cylinder, box-in-box piston, desmodromic distribution with titanium intake 4 valves, displacement 659 cc / 40.2 cu in , produces power 57 kW / 77.5 hp @ 9,750 rpm and 63 Nm / 46.5 lb-ft @ 8,000 rpm. Ducati Hypermotard 698 Mono / 698 Mono RVE weighs 151 kg / 332 lbs. Ducati Hypermotard 698 Mono / 698 Mono RVE has 8 photos.

Technical specifications

+ Add to 'Compare list'

Model:	Hypermotard 698 Mono / 698 Mono RVE
Years:	2024
Engine:	Four stroke, Superquadro single cylinder, box-in-box piston, desmodromic distribution with titanium intake 4 valves
Capacity:	659 cc / 40.2 cu in
Bore x Stroke:	116 x 62.4 mm
Cooling System:	Liquid cooled
Compression Ratio:	13.1;1
Exhaust:	1-2 exhaust system, double aluminium mufflers, catalytic converter and lambda probe
Emission:	EURO 5
Induction:	Electronic fuel injection system, 62mm throttle body with full Ride by Wire system
Starting:	Electric
Max Power:	57 kW / 77.5 hp @ 9,750 rpm
Max Torque:	63 Nm / 46.5 lb-ft @ 8,000 rpm
Clutch:	Slipper and self-servo wet multiplate clutch, hydraulic control
Transmission:	6 Speed with Ducati Quick Shift Up/Down
Final Drive:	Chain
Gear Ratio:	1st = 36/13, 2nd = 35/17, 3rd = 32/20, 4th 29/22, 5th 24/21, 6th 26/25
Primary Drive:	Straight cut gears, Ratio 1.968:1
Frame:	Steel trellis frame with tubes of different sections and thicknesses, steel tube subframe and aluminium double-sided swingarm
Front Suspension:	45 mm Marzocchi upside-down fork, fully adjustable, with upper adjusters for hydraulic calibrations
Front Wheel Travel:	215 mm / 8.5 in
Rear Suspension:	Fully adjustable Sachs monoshock with interposition of progressive linkages, external adjusters for hydraulic calibrations, wheel travel
Rear Wheel Travel:	240 mm / 9.4 in
Front Brakes:	Single 330 mm disc, with aluminium flange and Brembo M4.32 4-piston radial caliper
Rear Brakes:	Single 245mm disc single piston floating caliper
ABS:	Bosch-Brembo ABS 10.3ME Cornering braking system
Wheels:	Y-shaped 5 Spoke alloy wheels
Front Rim:	17 x 3.5
Rear Rim:	17 x 5.0
Front Tyre:	120/70 - ZR17
Rear Tyre:	160/60 - ZR17
Rake:	26.1?
Trail:	108 mm / 4.25 in
Wheelbase:	1443 mm / 56.8 in
Seat Height:	904 mm / 35.6 in
Dry Weight:	151 kg / 332 lbs
Wet Weight:	159.6 kg / 352 lbs
Fuel Capacity:	12.1 Litres / 3.2 US gal
Equipment::	Rider foot-rests optimised for sport riding with removable rubber covering for maximum grip with racing boots Full LED headlight with double-C DRL, Full-LED rear light Dashboard with 3.8? IBN (Improved Black Nematic) LCD screen with gear shift LED Lithium ion battery o Bosch Inertial Measurement Unit (IMU) 3 Power Modes (Low, Mid, High) 4 Riding Modes (Sport, Road, Urban, Wet) Ducati Wheelie Control (DWC) Ducati Traction Control (DTC) Engine Brake Control (EBC) Ducati Power Launch (DPL) Ducati Link Ready with infotainment apps Ducati Quick Shift (DQS) Up & Down
