Technical specifications
|
| Model: |
98T / 98TL |
| Years: |
1953-58 |
|
Engine:
|
Four stroke, single cylinder, OHV, pushrod
|
|
Capacity:
|
98 cc / 6.0 cu in
|
|
Bore x Stroke:
|
49 x 52 mm
|
|
Compression Ratio:
|
8:1
|
|
Cooling System:
|
Air cooled
|
|
Lubrication System:
|
Dry sump
|
|
Induction:
|
Dell' Orto MA16B carburetor
|
|
Ignition:
|
6V, 25W, Flywheel magneto
|
|
Starting:
|
Kick
|
|
Max Power:
|
4.3 kW / 5.8 hp @ 7500 rpm
|
|
Transmission:
|
3 Speed From 1957: 4 speed
|
|
Gear Ratios (from 1957):
|
1st: 2.690 / 2nd 1.850 / 3rd 1.365 / 4th 1.000:1
|
|
Final Drive:
|
Chain
|
|
Final Drive Ratio:
|
2.706
|
|
Frame:
|
Open spine pressed steel frame
|
|
Front Suspension:
|
Telescopic fork.
|
|
Rear Suspension:
|
Non-adjustable twin hydraulic shocks, swingarm
|
|
Front Brakes:
|
Drum
|
|
Rear Brakes:
|
Drum
|
|
Front Tyre:
|
2.50 - 17
|
|
Rear Tyre:
|
2.75 - 17
|
|
Dimensions:
|
Length: 1890 mm / 74.4 in
|
|
Wheelbase:
|
1245 mm / 49.0 in
|
|
Seat Height:
|
762 mm / 30.0 in
|
|
Dry Weight:
|
80 kg / 176 lbs
|
|
Fuel Capacity:
|
14 L / 3.7 US gal / 3.1 Imp gal
|
|
Top Speed:
|
75 km/h / 46.6 mph
|
