Technical specifications
|
| Model: |
800 Sport |
| Years: |
2003-04 |
|
Engine:
|
Four stroke, 90°“L”twin cylinder, SOHC, desmodromic 2 valves per cylinder, belt driven
|
|
Capacity:
|
803 cc / 49 cu in
|
|
Bore x Stroke:
|
88 x 66 mm
|
|
Compression Ratio:
|
10.5:1
|
|
Induction:
|
Marelli CPU 5.9M (45 mm throttle body) fuel injection
|
|
Spark plugs:
|
Champion RA4HC, NGK DCPR8E
|
|
Ignition:
|
Marelli electronic
|
|
Battery:
|
12V 10Ah
|
|
Starting:
|
Electric
|
|
Max Power:
|
54.3 kW / 74.5 hp @ 8250 rpm
|
|
Max Torque:
|
70 Nm / 7.1 kgf-m / 51.6 ft-lb @ 6250 rpm
|
|
Clutch:
|
Wet, multiplate
|
|
Transmission:
|
6 Speed
|
|
Primary Drive Ratio:
|
1.85:1 (33/61)
|
|
Gear Ratios:
|
1st 2.462 / 2nd 1.660 / 3rd 1.333 / 4th 1.130 / 5th 1.000 / 6th 0.923:1
|
|
Final Drive Ratio:
|
2.6:1 (15/39)
|
|
Final Drive:
|
Chain
|
|
Frame:
|
Trellis, welded high-strength 450ALS steel tubing
|
|
Front Suspension:
|
2003: Showa 43 mm fully adjustable upside-down fork 2004: Marzocchi 43 mm fully adjustable upside-down fork
|
|
Rear Suspension:
|
Progressive cantilever linkage with fully adjustable Sage Boge monoshock, steel swing arm
|
|
Front Brakes:
|
2x 320 mm Discs, 4 piston calipers
|
|
Rear Brakes:
|
Single 245 mm disc, 2 piston caliper
|
|
Front Tyre:
|
120/70-17
|
|
Rear Tyre:
|
170/60-17
|
|
Dimensions:
|
Length: 2030 mm / 79.9 in Width: 780 mm / 30.7 in Height: 1110mm / 43.7 in
|
|
Wheelbase:
|
1405 mm / 55.3 in
|
|
Seat Height:
|
815 mm / 32.1 in
|
|
Dry Weight:
|
182 kg / 402 lbs
|
|
Fuel Capacity:
|
16 L/ 16 L / 4.2 US gal / 3.5 Imp gal
|
|
Top Speed:
|
210 km/h / 131 mph
|
|
Colours:
|
Red, Yellow, Silver gray
|
