Ducati 750 Supersport (1994-95) technical specifications
Ducati 750 Supersport is produced in 1994-95. Engine is Four stroke, 90°“L”twin cylinder, DOHC, desmodromic 4 valves per cylinder, belt driven, displacement 748 cc / 45.6 cu-in , produces power 48.5 kW / 66 hp @ 8500 rpm and 72 Nm / 7.3 kgf-m / 53.1 ft-lb @ 6500 rpm. Ducati 750 Supersport top speed is 220 km/h / 124 mph. Ducati 750 Supersport weighs 176 kg / 388 lbs. Ducati 750 Supersport has 3 photos.
Technical specifications
+ Add to 'Compare list'| Model: | 750 Supersport |
| Years: | 1994-95 |
| Engine: | Four stroke, 90°“L”twin cylinder, DOHC, desmodromic 4 valves per cylinder, belt driven |
| Capacity: | 748 cc / 45.6 cu-in |
| Bore x Stroke: | 88 x 61.5 mm |
| Cooling System: | Air cooled |
| Oil Capacity: | 3.2 L / 3.4 US qt / 2.8 Imp qt |
| Compression Ratio: | 9.0:1 |
| Induction: | Mikuni BDST 38-B70 carburetors |
| Spark Plug: | Champion RA6HC |
| Ignition: | Kokusan electronic |
| Battery: | Yuasa 12V 14Ah |
| Starting: | Electric |
| Max Power: | 48.5 kW / 66 hp @ 8500 rpm |
| Max Torque: | 72 Nm / 7.3 kgf-m / 53.1 ft-lb @ 6500 rpm |
| Clutch: | Wet, multiplate |
| Transmission: | 5 Speed |
| Primary Drive Ratio: | 2.000:1 (31/62) |
| Gear Ratios: | 1st 2.500 / 2nd 1.714 / 3rd 1.333 / 4th 1.074 / 5th 0.966:1 |
| Final Drive Ratio: | 2.466:1 (15/37) |
| Final Drive: | Chain |
| Front Suspension: | Marzocchi 40 USD/E inverted telescopic fork |
| Front Wheel Travel: | 119 mm / 4.7 in |
| Rear Suspension: | Showa GD 022-007-OX monoshock, cantilever swingarm |
| Rear Wheel Travel: | 135 mm / 5.3in |
| Front Brakes: | 2 x 320 mm Discs, 2 piston calipers |
| Rear Brakes: | Single 245 mm disc, 2 piston caliper |
| Front Wheel: | 3.50 x 17 |
| Rear Wheel: | 5.50 x 17 |
| Front Tyre: | 120/60-17, Dunlop Sportmax Radial |
| Rear Tyre: | 170/60-17, Dunlop Sportmax Radial |
| Dimensions: | Length: 2000 mm / 78.7 in Width: 730 mm / 28.7 in Height: 1125 mm / 44.3 in |
| Wheelbase: | 1410 mm / 55.5 in |
| Seat Height: | 780 mm / 30.7 in |
| Ground Clearance: | 130 mm / 5.1 in |
| Rake: | 25° |
| Trail: | 104 mm / 4.1 in |
| Dry Weight: | 176 kg / 388 lbs |
| Wet Weight: | 188 kg / 416 lbs |
| GVWR: | 341 kg / 752 lbs |
| Fuel Capacity: | 17.5 L / 4.6 US gal / 3.8 Imp gal |
| Consumption Average: | 5.7 L/100 km / 17.3 km/l / 41 US mpg / 49 Imp mpg |
| Standing ¼ Mile: | 12.1 sec / 174 km/h / 108 mph |
| Top Speed: | 220 km/h / 124 mph |
| Colours: | White frame, red or black |
| Manual: | The Motorhead |
