Ducati 750 Paso Limited (1988) technical specifications
Ducati 750 Paso Limited is produced in 1988. Engine is Four stroke, 90°“L” twin cylinder, SOHC desmodromic 2 valve per cylinder, belt driven, displacement 748 cc / 45.6 cu in , produces power 53.3 kW / 72.5 hp @ 7900 rpm and 70.4 Nm / 7.2 kgf-m / 52 ft-lb @ 7000 rpm. Ducati 750 Paso Limited top speed is 210 km/h / 130.5 mph. Ducati 750 Paso Limited weighs 195 kg / 430 lbs. Ducati 750 Paso Limited has 2 photos.
Technical specifications
+ Add to 'Compare list'| Model: | 750 Paso Limited |
| Years: | 1988 |
| Engine: | Four stroke, 90°“L” twin cylinder, SOHC desmodromic 2 valve per cylinder, belt driven |
| Capacity: | 748 cc / 45.6 cu in |
| Bore x Stroke: | 88 x 61.5 mm |
| Compression Ratio: | 10:1 |
| Induction: | Weber 44DCNF 107 carburetor |
| Spark Plugs: | Champion RA6YC |
| Ignition: | Kokusan electronic |
| Battery: | Yuasa 12V 14Ah |
| Starting: | Electric |
| Max Power: | 53.3 kW / 72.5 hp @ 7900 rpm |
| Max Torque: | 70.4 Nm / 7.2 kgf-m / 52 ft-lb @ 7000 rpm |
| Clutch: | Dry, multiplate |
| Transmission: | 5 Speed |
| Primary Drive Ratio: | 1.972:1 (31/71) |
| Gear Ratios: | 1st 2.500 / 2nd 1.714 / 3rd 1.333 / 4th 1.074 / 5th 0.966:1 |
| Final Drive Ratio: | 2.533:1 (15/38) |
| Final Drive: | Chain |
| Front Suspension: | 42 mm Marzocchi M1R fork |
| Rear Suspension: | Öhlins mono shock, rising rate swingarm |
| Front Brakes: | 2 x 280 mm Discs |
| Rear Brakes: | Single 270 mm disc |
| Front Tyre: | 110/90 -18 |
| Rear Tyre: | 140/90 -15 |
| Dimensions: | Length: 2032 mm / 80.0 in Width: 655 mm / 25.8 in Height: 1150 mm / 42.3 in |
| Wheelbase: | 1450 mm / 57.1 in |
| Seat Height: | 780 mm / 30.7 in |
| Dry Weight: | 195 kg / 430 lbs |
| Fuel Capacity: | 22 L / 5.8 US gal / 4.8 Imp gal |
| Consumption Average: | 5.4 l/100 km / 18.6 km/l / 43.7 US mpg / 52.5 Imp mpg |
| Top Speed: | 210 km/h / 130.5 mph |
| Colours: | Red, white, blue |
