Ducati 1299S Panigale Anniversario (2016) technical specifications

Ducati 1299S Panigale Anniversario is produced in 2016. Engine is Four stroke, 90° “L” twin cylinder, DOHC, desmodromic 4 valve per cylinder., displacement 1285 cc / 78.4 cub in , produces power 150.8 kW / 205 hp @ 10500 rpm and 144.6 Nm / 14.7 kgf-m / 106.7 lb-ft @ 8750 rpm. Ducati 1299S Panigale Anniversario weighs 164 kg / 361.5 lbs. Ducati 1299S Panigale Anniversario has 7 photos.

Technical specifications

+ Add to 'Compare list'

Model:	1299S Panigale Anniversario
Years:	2016
Engine:	Four stroke, 90° “L” twin cylinder, DOHC, desmodromic 4 valve per cylinder.
Capacity:	1285 cc / 78.4 cub in
Bore x Stroke:	116 x 60.8 mm
Cooling System:	Liquid cooled
Compression Ratio:	12.6:1
Lubrication:	Wet sump
Induction:	Mitsubishi EFI, twin injectors per cylinder, full ride-by-wire elliptical throttle bodies
Exhaust:	2-1-2 Titanium system with catalytic converter and 2 lambda probes. Twin stainless steel mufflers with aluminium end caps
Emissions:	Euro 3
Ignition:	Digital CDI
Starting:	Electric
Max Power:	150.8 kW / 205 hp @ 10500 rpm
Max Torque:	144.6 Nm / 14.7 kgf-m / 106.7 lb-ft @ 8750 rpm
Clutch:	Slipper and self-servo wet multiplate clutch with hydraulic control
Transmission:	6 Speed with Ducati Quick Shift
Final Drive:	Chain 525; front sprocket 15, rear sprocket 39
Primary drive:	Straight cut gears, ratio 1.77:1
Gear Ratio:	1st 37/15 / 2nd 30/16 / 3rd 27/18 / 4th 25/20 / 5th 24/22 / 6th 23/24
Frame:	Monocoque aluminum
Front Suspension:	Öhlins NIX30, 43mm fully adjustable USD fork with TiN treatment. Electronic compression and rebound damping adjustment with semi-active mode
Front Wheel Travel:	120 mm / 4.72 in
Rear Suspension:	Fully adjustable Öhlins TTX36 unit. Electronic compression and rebound damping adjustment. Adjustable linkage: Progressive/flat. Aluminum single-sided swingarm, 4-point adjustable pivot.
Rear Wheel Travel:	130m m / 5.12 in
Front Brakes:	2 x 330 mm Semi-floating discs, radially mounted Brembo Monobloc EVO M50 4-piston calipers with cornering ABS Bosch 9.1 MP
Rear Brakes:	Single 245 mm disc 2 piston caliper with cornering ABS
Front Tyre:	120/70 ZR17 Pirelli Diablo Supercorsa SP
Rear Tyre:	200/55 ZR17 Pirelli Diablo Supercorsa SP
Front wheel:	3-Spoke forged light alloy 3.50" x 17"
Rear wheel:	3-Spoke forged light alloy 6.00" x 17"
Rake:	24°
Trail:	96 mm / 3.78 in
Steering lock (total):	48°
Dimensions:	Height 1130 mm / 44.1 in Length 2060 mm / 81.1 in
Wheelbase:	1437 mm / 56.57 in
Seat Height:	830 mm / 32.7 in
Dry Weight:	164 kg / 361.5 lbs
Fuel Capacity:	17 Litres / 4.5 US gal / 3.7 Imp gal
