Ducati 125 Sport (1965-67) technical specifications
Ducati 125 Sport is produced in 1965-67. Engine is Four stroke, single-cylinder, OHC, bevel gear driven, displacement 124.4 cc / 7.6 cu in , produces power 7.5 kW / 10 hp @ 8500 rpm. Ducati 125 Sport top speed is 112 km/h / 69 mph. Ducati 125 Sport weighs 100.5 kg / 221 lbs. Ducati 125 Sport has 2 photos.
Technical specifications
+ Add to 'Compare list'| Model: | 125 Sport |
| Years: | 1965-67 |
| Engine: | Four stroke, single-cylinder, OHC, bevel gear driven |
| Capacity: | 124.4 cc / 7.6 cu in |
| Bore x Stroke: | 55.2 x 52 mm |
| Compression Ratio: | 8.0:1 |
| Cooling System: | Air cooled |
| Lubrication System: | Forced oil sump |
| Induction: | Dell'Orto UB20BS carburetor |
| Ignition: | Battery and coil, 6V 40W generator |
| Spark Plug: | Marelli CW260N |
| Battery: | SAFA 3L3, 13.5 Ah |
| Starting: | Kick |
| Max Power: | 7.5 kW / 10 hp @ 8500 rpm |
| Primary Drive Ratio: | 3.00:1 |
| Transmission: | 4 Speed |
| Gear Ratios: | 1st 2.75 / 2nd 1.65 / 3rd 1.18 / 4th 0.97:1 |
| Clutch: | Wet, multi-plate |
| Final Drive: | Chain |
| Final Drive Ratio: | 2.750:1 |
| Frame: | Single tubular downpipe cradle |
| Front Suspension: | Hydraulically damped telescopic forks, Marzocci |
| Rear Suspension: | Swingarm, dual shocks, 3-way adjustable |
| Front Brakes: | Drum |
| Rear Brakes: | Drum |
| Front Tyre: | 2.50 - 17 CEAT |
| Rear Tyre: | 2.75 - 17 CEAT |
| Dimensions: | Length:1910 mm / 72.2 in Width: 580 mm / 22.8 in Height: 920 mm / 36.2 in |
| Wheelbase: | 1320 mm / 52.0 in in |
| Dry Weight: | 100.5 kg / 221 lbs |
| Fuel Capacity: | 16 L / 4.2 US gal / 3.5 Imp gal |
| Top Speed: | 112 km/h / 69 mph |
