Technical specifications
|
| Model: |
125 Cadet/4 / Cadet/4 Lusso / Cadet/4 Scrambler |
| Years: |
1967-68 |
|
Engine:
|
Four stroke, single-cylinder, OHV, pushrod
|
|
Capacity:
|
121.3 cc / 7.4 cu in
|
|
Bore x Stroke:
|
53 x 55 mm
|
|
Compression Ratio:
|
8.4:1
|
|
Cooling System:
|
Air cooled
|
|
Lubrication System:
|
Dry sump
|
|
Induction:
|
Dell'Orto ME18BS
|
|
Ignition:
|
6V, 28W generator, coil
|
|
Starting:
|
Kick
|
|
Max Power:
|
4.8 kW / 6.5 hp @ 6500 rpm
|
|
Transmission:
|
4 Speed
|
|
Final Drive:
|
Chain
|
|
Front Suspension:
|
Marzocchi hydraulically damped telescopic forks
|
|
Rear Suspension:
|
Swingarm, dual chocks
|
|
Front Brakes:
|
118 mm Drum
|
|
Rear Brakes:
|
118 mm Drum
|
|
Front Tyre:
|
1967 Cadet: 2.25 x 18 1968 Cadet & Lusso: 2.50 x 18 Scrambler: 2.75 x 18
|
|
Rear Tyre:
|
1967 Cadet: 2.50 x 18 1968 Cadet & Lusso: 2.75 x 18 Scrambler: 3.25 - 3.50 x 16
|
|
Dimensions:
|
Length: 1810 mm / 71.3 in Height: 770 mm / 30.3 in
|
|
Wheelbase:
|
1160 mm / 45.7 in
|
|
Seat Height:
|
670 mm / 26.4 in
|
|
Dry Weight:
|
Cadet & Lusso: 72 kg / 59 lbs Scrambler: 75 kg / 165 lbs
|
|
Fuel Capacity:
|
14 L / 3.7 Us gal / 3.1 Imp gal
|
|
Top Speed:
|
Cadet & Lusso: 95 km/h / 59 mph Scrambler: 80 km/h / 50 mph
|
