Ducati 125 Bronco (1960-66) technical specifications
Ducati 125 Bronco is produced in 1960-66. Engine is Four stroke, single cylinder, OHV, pushrod, displacement 124.4 cc / 7.6 cu in , produces power 4.8 kW / 6.5 hp @ 6500 rpm. Ducati 125 Bronco top speed is 86 km/h / 53.4 mph. Ducati 125 Bronco weighs 91 kg / 200 lbs. Ducati 125 Bronco has 3 photos.
Technical specifications
+ Add to 'Compare list'| Model: | 125 Bronco |
| Years: | 1960-66 |
| Engine: | Four stroke, single cylinder, OHV, pushrod |
| Capacity: | 124.4 cc / 7.6 cu in |
| Bore x Stroke: | 55.2 × 52 mm |
| Compression Ratio: | 6.8:1 |
| Cooling System: | Air cooled |
| Induction: | Dell' Orto ME18BS carburetor |
| Ignition: | 6V, 28W, Flywheel magneto |
| Starting: | Kick |
| Max Power: | 4.8 kW / 6.5 hp @ 6500 rpm |
| Transmission: | 4 Speed |
| Final Drive: | Chain |
| Gear Ratio: | 1st 2.69 / 2nd 1.85 / 3rd 1.36 / 4th 1:1 |
| Frame: | Tubular steel, duplex full cradle |
| Front Suspension: | Marzocchi hydraulically damped telescopic fork. |
| Rear Suspension: | Non-adjustable twin hydraulic shock swingarm. |
| Front Brakes: | 123 x 25 mm Double shoe drum |
| Rear Brakes: | 123 x 25 mm Double shoe drum |
| Front Tyre: | 2.75 - 16 |
| Rear Tyre: | 2.75 - 16 |
| Dimensions: | Length 1920 mm / 75.68 in Height 910 mm / 35.8 in |
| Wheelbase: | 1285 mm / 50.6 in |
| Seat Height: | 790 mm / 31.1 in |
| Dry Weight: | 91 kg / 200 lbs |
| Wet Weight: | 103.3 kg / 228 lbs |
| Fuel Capacity: | 13 Litres / 3.4 US gal / 2.9 Imp gal |
| Top Speed: | 86 km/h / 53.4 mph |
