Ducati 1198SP (2011) technical specifications

Ducati 1198SP is produced in 2011. Engine is Four stroke, 90°“L”twin cylinder, DOHC, desmodromic 4 valve per cylinder, displacement 1198 cc / 73.1 cu in , produces power 125 kW / 170hp @ 9750 rpm and 131.4 Nm / 13.4 kgf-m / 97 lb-ft @ 8000 rpm. Ducati 1198SP top speed is 280.9 km/h / 174.5 mph. Ducati 1198SP weighs 168 kg / 370.3 lbs. Ducati 1198SP has 7 photos.

Technical specifications

+ Add to 'Compare list'

Model:	1198SP
Years:	2011
Engine:	Four stroke, 90°“L”twin cylinder, DOHC, desmodromic 4 valve per cylinder
Capacity:	1198 cc / 73.1 cu in
Bore x Stroke:	106 x 67.9 mm
Compression Ratio:	12.7:1
Cooling System:	Liquid cooled
Lubrication System:	Wet sump
Engine Oil:	Synthetic, 20W-50
Induction:	Marelli electronic fuel injection, elliptical throttle bodies
Exhaust:	Lightweight 2-1-2 system with catalytic converter and 2 lambda probes, twin stainless steel mufflers
Ignition:	Digital CDI
Starting:	Electric
Max Power:	125 kW / 170hp @ 9750 rpm
Max Torque:	131.4 Nm / 13.4 kgf-m / 97 lb-ft @ 8000 rpm
Clutch:	Dry multiplate with hydraulic control slipper clutch
Transmission:	6 Speed
Primary drive:	Straight cut gears, ratio 1.84:1
Final drive:	Chain, front sprocket 15; rear sprocket 38
Gear Ratio:	1st 37/15 / 2nd 30/17 / 3rd 28/20 / 4th 26/22 / 5th 24/23 / 6th 22/25
Frame:	Tubular steel Trellis frame
Front Suspension:	Öhlins 43mm with TiN fully adjustable upside-down fork
Front Wheel Travel:	120 mm / 4.7 in
Rear Suspension:	Progressive linkage with fully adjustable Öhlins TTX monoshock with top-out spring. Aluminium single-sided swingarm
Rear Wheel travel:	127 mm / 5.0 in
Front Brakes:	2 x 330 mm Semi-floating discs, radially mounted Brembo Monobloc calipers, 4-piston, 2-pad.
Rear Brakes:	Single 245 mm disc 2 piston caliper
Front Wheel:	7-Spoke light alloy, 3.50 x 17
Front Tyre:	120/70 ZR17
Rear Wheel:	7-Spoke light alloy, 6.00 x 17
Rear Tyre:	190/55 ZR17
Dimensions:	Length 2100mm / 82.6in Height 1100mm / 43.3in
Wheelbase:	1430mm / 56.3 in
Rake:	24°30' / 24.5°
Steering angle:	28°30' / 28.5°
Seat Height:	820mm / 32.2in
Dry Weight:	168 kg / 370.3 lbs
Fuel Capacity:	18 Litres / 4.75 US gal / 4.0 Imp gal
Standing ¼ Mile:	10.2 sec
Top Speed:	280.9 km/h / 174.5 mph
Road Test:	IN MOTO
