Technical specifications
|
| Model: |
W8 125 |
| Years: |
1991-99 |
|
Engine:
|
Two stroke, single cylinder
|
|
Capacity:
|
125 cc / 7.6 cu-in
|
|
Bore x Stroke:
|
56 x 50.6 mm
|
|
Cooling System:
|
Liquid cooled
|
|
Compression Ratio:
|
13.0:1
|
|
Induction:
|
Single carburetor
|
|
Ignition:
|
Electronic
|
|
Starting:
|
Kick
|
|
Max Power:
|
30 hp / 22 kW @ 9400 rpm
|
|
Max Torque:
|
19.9 Nm / 14.6 lb-ft @ 9400 rpm
|
|
Clutch:
|
Wet multiplate
|
|
Transmission:
|
6 Speed
|
|
Final Drive:
|
Chain
|
|
Front Suspension:
|
Telescopic forks
|
|
Rear Suspension:
|
Single shock
|
|
Front Brakes:
|
Single disc
|
|
Rear Brakes:
|
Single disc
|
|
Front Tyre:
|
90/90-21
|
|
Rear Tyre:
|
120/90-18
|
|
Wet Weight:
|
127.8 kg / 282 lbs
|
|
Fuel Capacity:
|
14 Litres / 3.7 US gal
|
|
Consumption average:
|
15.8 km/lit
|
|
Braking 60 - 0 / 100 - 0:
|
13.6 m / 39.9 m
|
|
Standing ¼ Mile:
|
15.2 sec / 134.3 km/h
|
|
Top Speed:
|
136.6 km/h / 84.8 mph
|
