Cagiva Navigator 1000 (2000-01) technical specifications

Cagiva Navigator 1000 technical specifications

Cagiva Navigator 1000 is produced in 2000-01. Engine is Four stroke, 90°-V-twin, DOHC, 4 valves per cylinder (Suzuki TL1000), displacement 996 cc / 60.7 cu-in , produces power 99 ho / 73 kW @ 8500 rpm and 95 Nm / 9.7 kgf-m @ 7000 rpm. Cagiva Navigator 1000 top speed is 211.6 km/h. Cagiva Navigator 1000 weighs 210 kg / 463 lbs. Cagiva Navigator 1000 has 4 photos.

Technical specifications

+ Add to 'Compare list'
Model: Navigator 1000
Years: 2000-01
Engine: Four stroke, 90°-V-twin, DOHC, 4 valves per cylinder (Suzuki TL1000)
Capacity: 996 cc / 60.7 cu-in
Bore x Stroke: 98 X 66 mm
Cooling System: Liquid cooled
Compression Ratio: 11.3:1
Induction: Electronic fuel injection
Ignition: Electronic, transistorized
Starting: Electric
Max Power: 99 ho / 73 kW @ 8500 rpm
Max Torque: 95 Nm / 9.7 kgf-m @ 7000 rpm
Clutch: Cable-operated multi-plate wet clutch.
Transmission: 6 Speed
Final Drive: Chain
Front Suspension: 45mm Telescopic hydraulic fork
Front Wheel Travel: 150 mm / 5.9 in
Rear Suspension: Progressive with hydraulic monoshock, preload and rebound damping adjustable.
Rear Wheel Travel: 160 mm / 6.3 in
Front Brakes: 2x 298mm discs 4 piston calipers
Rear Brakes: Single 220mm disc 2 piston caliper
Front Tyre: 110/80-18
Rear Tyre: 150/70-17
Seat Height: 850 mm / 33.5 in
Ground Clearance: 150 mm / 5.9 in
Dry Weight: 210 kg / 463 lbs
Wet Weight: 225 kg / 496 lbs
Fuel Capacity: 20 Litres / 5.3 US gal
Consumption Average: 17.3 km/lit
Standing ¼ Mile: 12.0 sec
Top Speed: 211.6 km/h
