Buell / EBR Buell XB12X Ulysses Adventure (2010) technical specifications
Buell / EBR Buell XB12X Ulysses Adventure is produced in 2010. Engine is 45° V-Twin, four stroke, pushrod actuated overhead valve, hydraulic self-adjusting lifters, 2 valve per cylinder., displacement 1203 cc / 73 cu in , produces power 86.9 kW / 103 hp @ 6800 rpm and 114 Nm / 11.6 kgf-m / 84 ft-lbs @ 6000 rpm. Buell / EBR Buell XB12X Ulysses Adventure top speed is 202 km/h / 126 mph. Buell / EBR Buell XB12X Ulysses Adventure weighs 193 kg / 425 lbs. Buell / EBR Buell XB12X Ulysses Adventure has 3 photos.
Technical specifications
+ Add to 'Compare list'| Model: | Buell XB12X Ulysses Adventure |
| Years: | 2010 |
| Engine: | 45° V-Twin, four stroke, pushrod actuated overhead valve, hydraulic self-adjusting lifters, 2 valve per cylinder. |
| Capacity: | 1203 cc / 73 cu in |
| Bore x Stroke: | 88.9 x 96.8 mm |
| Compression Ratio: | 10.0:1 |
| Cooling System: | Air cooled |
| Lubrication: | Dry sump |
| Exhaust: | Buell InterActive Exhaust |
| Induction: | Ø49 mm downdraft DDFI II fuel injection |
| Starting: | Electric |
| Battery: | 12V, 12Ah |
| Max Power: | 86.9 kW / 103 hp @ 6800 rpm |
| Max Torque: | 114 Nm / 11.6 kgf-m / 84 ft-lbs @ 6000 rpm |
| Clutch: | Wet, multi-plate |
| Transmission: | 5 Speed |
| Final Drive: | Belt |
| Gear Ratios: | 1st 2.648 / 2nd 1.892 / 3rd 1.407 / 4th 1.166 / 5th 1.000 |
| Frame: | Aluminium frame with Uniplanar™ Powertrain vibration isolation system, fuel in frame |
| Rake: | 22° |
| Trail: | 122 mm / 4.8" |
| Front Suspension: | Showa Ø43 mm inverted forks compression damping, rebound damping and spring preload adjustable |
| Front Wheel Travel: | 165 mm / 6.5" |
| Rear Suspension: | Showa coil-over monoshock, remote underseat reservoir and adjustable compression damping, rebound damping and spring preload |
| Rear Wheel Travel: | 163 mm / 6.4" |
| Front Brakes: | ZTL type brake, 6 piston, fixed caliper, Ø375 mm single-sided, inside out, stainless steel, floating rotor |
| Rear Brakes: | Single Ø240 mm disc, 1 piston floating caliper |
| Wheels: | 6-Spoke, ZTL cast aluminium |
| Front Wheel: | 3.50 x 17" |
| Rear Wheel: | 5.50 x 17" |
| Front Tyre: | 120/70 R17 Dunlop D616F |
| Rear Tyre: | 180/55 R17 Dunlop D616 |
| Dimensions: | Length: 2159 mm / 85.0" Width: 755 mm / 29.7" Height: 1331 mm / 52.4" |
| Wheelbase: | 1372 mm / 54.0" |
| Ground Clearance: | 171 mm / 6.75" |
| Seat Height: | 841 mm / 33.1" |
| Dry Weight: | 193 kg / 425 lbs |
| GVWR: | 430 kg / 950 lbs |
| Fuel Capacity: | 16.7 L / 4.4 US gal |
| Fuel Reserve: | 3.1 L / 0.82 US gal |
| Oil Capacity: | 2.37 L / 2.50 qts |
| Standing ¼ Mile: | 12.8 sec |
| Top Speed: | 202 km/h / 126 mph |
| Reviews: | Motorbikes Today / Motocorse / Momenridersnow.com / MMotorline.cc / MC24.no |
