BMW RNineT (2019) technical specifications

BMW RNineT is produced in 2019. Engine is Four stroke, two cylinderhorizontally opposed Boxer, two camshafts and four radially alignedvalves per cylinder, central counterbalancer shaft., displacement 1170 cc /71.4 cub in. , produces power 81 kW / 110 hp @ 7550 rpm and 116 Nm / 11.8 kgf-m/ 85.6 lb-ft @ 6000rpm. BMW RNineT weighs 220kg / 485 lbs. BMW RNineT has 8 photos.

Technical specifications

+ Add to 'Compare list'

Model:	RNineT
Years:	2019
Engine:	Four stroke, two cylinderhorizontally opposed Boxer, two camshafts and four radially alignedvalves per cylinder, central counterbalancer shaft.
Capacity:	1170 cc /71.4 cub in.
Bore x Stroke:	101 x 73 mm
Cooling System:	Air/Oil cooled
Compression Ratio:	12.0:1
Lubrication:	Wetsump
Induction:	Electronic intake pipe injection / digital enginemanagement with overrun cutoff, twin-spark ignition
Emission Control:	Controlled 3-way catalytic converter, exhaust emissionstandards EU-4
Alternator:	Three-phase alternator 600W
Battery:	12 V / 14 Ah, maintenance-free
Starting:	Electric
Max Power:	81 kW / 110 hp @ 7550 rpm
Max Torque:	116 Nm / 11.8 kgf-m/ 85.6 lb-ft @ 6000rpm
Clutch:	Single dry plate clutch, hydraulically operated
Transmission :	Constant mesh6-speed
Final Drive:	Shaft
Gear Ratios:	Ist 2.375 / 2nd 1.696 /3rd 1.296 / 4th 1.065 / 5th 0.939 / 6th0.848:1
Frame:	Four-part frame concept with front frameand three-part rear frame, load-bearing engine-gearbox unit,rear-seat frame removeable for one-up riding
Front Suspension:	Upside-down telescopic forks, 46 mm fixed-fork-tube diameter
Front Wheel Travel:	120 mm / 4.7 in
Rear Suspension:	Cast aluminium single swinging arm with BMW MotorradParalever; central spring strut,spring preload fully adjustable byhook wrench, adjustable rebound-stage damping
Rear Wheel Travel:	120 mm / 4.7 in
Front Brakes:	2 x 320 mm Foating brake discs, 4 pistonradial calipers
Rear Brakes:	Single 265 mmdisc, 2 piston floating caliper
ABS:	BMW Motorrad ABS
Rim Front:	3.50 x 17, Cast alloy
Rim Rear:	5.50 x 17, Cast alloy
Front Tyre:	120/70 - ZR17
Rear Tyre:	180/55 - ZR17
Castor:	107.9mm / 4.2in
Steering Head Angle:	63.2 °
Dimensions:	Length 2110 mm/ 83.1 inWidth 900 mm / 35.4in (incl.mirrors) Height 1240 mm /48.8 in (excl.mirrors)
Wheelbase:	1522 mm / 59.9 in
Seat Height:	820 mm / 32.3in
Inner Leg Curve:	1795 mm / 70.7 in unladen
GVWR:	430kg / 948 lbs
Dry Weight:	220kg / 485 lbs
Fuel Capacity :	18 Litres / 4.7 US gal / 3.7 Impgal
