BMW R 1200R LC (2017-18) technical specifications
BMW R 1200R LC is produced in 2017-18. Engine is Fourstroke, two cylinder horizontally opposed Boxer, DOHC, 4 valves percylinder, intake 40mm, outlet 34 mm, displacement 1170 cc / 71.4 cubin. , produces power 92 kW / 125 hp @ 7750 rpm and 125 Nm / 12.7 kgf-m / 92 lb-ft @ 6500 rpm. BMW R 1200R LC wet weight is 231 kg / 509.2 lbs. BMW R 1200R LC has 3 photos.
Technical specifications
+ Add to 'Compare list'| Model: | R 1200R LC |
| Years: | 2017-18 |
| Engine: | Fourstroke, two cylinder horizontally opposed Boxer, DOHC, 4 valves percylinder, intake 40mm, outlet 34 mm |
| Capacity: | 1170 cc / 71.4 cubin. |
| Bore x Stroke: | 101 x 73 mm |
| Cooling System: | Liquid /Air cooled |
| Compression Ratio: | 12.5:1 |
| Induction: | Throttle valve mm 52Carburetion BMS-XEmission control Closed-loop 3-way catalytic converter |
| Fuel: | Premium unleaded (95 RON) |
| Ignition : | BMS-K |
| Alternator: | Three-phase alternator 510 W(nominal power) |
| Battery: | 12 V / 11,8 Ah,maintenance-free |
| Starting: | Electric |
| Electrical system: | Alternator three-phasealternator 508 W (nominal power)Battery /Ah 12V/12 maintenance-freeHeadlight H7W / LED (SA)Starter 0.9 kW |
| Max Power: | 92 kW / 125 hp @ 7750 rpm |
| Max Torque: | 125 Nm / 12.7 kgf-m / 92 lb-ft @ 6500 rpm |
| Clutch: | Oil lubricated clutch, hydraulically operated |
| Transmission : | Constant mesh 6-speed gearboxwith helical gear teeth |
| Final Drive: | Shaft |
| Frame: | Two-section frame, front- and boltedon rear frame, load-bearing engine |
| Front Suspension: | Telescopic Upside-Down fork;stanchion diameter 45 mm |
| Front Wheel Travel: | 140 mm / 5.5 in |
| Rear Suspension: | Cast aluminium single-sided swingarm with BMW Motorrad Paralever; WAD strut (travel-relateddamping), spring pre-load hydraulically adjustable (continuouslyvariable) at handwheel, rebound damping adjustable athandwheel |
| Rear Wheel Travel: | 140 mm / 5.5 in |
| Front Brakes: | 2 x 320 floating discs, 4piston calipers |
| Rear Brakes: | Single 275mm disc, 2 pistoncaliper |
| ABS: | BMW Motorrad Integral ABS(part-integral), disengageable |
| Front Rim: | 3.50 x 17" |
| Rear Rim: | 5.50 x 17" |
| Front Tyre: | 120/70 ZR 17 |
| Rear Tyre: | 180/55 ZR 17 |
| Wheel Castor: | 125,6 mm / 4.9 in |
| Steering Head Angle: | 62.3° |
| Dimensions: | Length 2165 mm / 85.2 inWidth 880 mm / 34.6 in (incl. mirrors)Height 1300 mm / 51.1 in (excl. mirrors) |
| Wheelbase: | 1515 mm / 59.6 in |
| Seat Height: | 760 mm - 820 mm / 29.9 in - 32.2in |
| Wet Weight: | 231 kg / 509.2 lbs |
| Permitted Total Weight: | 450 kg / 992lbs |
| Fuel Capacity : | 18 Liters / 5.3 USgal |
| Reserve: | 4 Litres / 1.0 US gal |
