BMW R 1200GS LC Adventure (2016) technical specifications
BMW R 1200GS LC Adventure is produced in 2016. Engine is Four stroke, two cylinder horizontally opposed Boxer, DOHC, 4 valves per cylinder, intake 40mm, outlet 34 mm, displacement 1170 cc / 71.4 cub in. , produces power 92 kW / 125 hp @ 7750 rpm and 125 Nm / 12.7 kgf-m / 92 lb-ft @ 6500 rpm. BMW R 1200GS LC Adventure weighs 220 kg / 485 lbs. BMW R 1200GS LC Adventure has 3 photos.
Technical specifications
+ Add to 'Compare list'| Model: | R 1200GS LC Adventure |
| Years: | 2016 |
| Engine: | Four stroke, two cylinder horizontally opposed Boxer, DOHC, 4 valves per cylinder, intake 40mm, outlet 34 mm |
| Capacity: | 1170 cc / 71.4 cub in. |
| Bore x Stroke: | 101 x 73 mm |
| Cooling System: | Liquid / Air cooled |
| Compression Ratio: | 12.5:1 |
| Induction: | Throttle valve 52 mm Carburetion BMS-X Emission control Closed-loop 3-way catalytic converter |
| Fuel: | Premium unleaded (95 RON) |
| Ignition: | BMS-K |
| Alternator: | Three-phase alternator 620 W (nominal power) |
| Battery: | 12 V / 11.8 maintenance-free |
| Starting: | Electric |
| Electrical system: | Headlight H7W / LED (SA) Starter 0.9 kW |
| Exhaust management: | Fully-controlled three-way catalytic converter |
| Max Power: | 92 kW / 125 hp @ 7750 rpm |
| Max Torque: | 125 Nm / 12.7 kgf-m / 92 lb-ft @ 6500 rpm |
| Clutch: | Anti-hopping wet clutch |
| Transmission: | 6 Speed |
| Final Drive: | Shaft |
| Gear Ratios: | 1st 2.438 / 2nd 1.714 / 3rd 1.296 / 4th 1.059 / 5th 0.943 / 6th 0.848:1 |
| Transmission Ratio: | 2.91:1 |
| Frame: | Tubular steel bridge frame, engine self-supporting |
| Front Suspension: | BMW Motorrad Telelever; diameter 37 mm, central spring strut |
| Front Wheel Travel: | 210 mm / 8.3 in. |
| Rear Suspension: | Cast aluminium single-sided swing arm with BMW Motorrad Paralever; WAD strut (travel-related damping), spring preload hydraulically adjustable (continuously variable) at handwheel, rebound damping adjustable at handwheel |
| Rear Wheel Travel: | 220 mm / 8.7 in |
| Front Brakes: | 2x 305mm Hydraulically actuated twin disc brake, BMW Motorrad Integral ABS (standard, part intergal, disengageable) |
| Rear Brakes: | Single 275mm disc 2 piston caliper, BMW Motorrad Integral ABS (standard, part intergal, disengageable) |
| Front Wheel: | Cast aluminum wheels laced wire spokes |
| Rear Wheel: | Cast aluminum wheels laced wire spokes |
| Front Rim: | 3.00 x 19 |
| Rear Rim: | 4.50 x 17 |
| Front Tyre: | 120/70 R19 |
| Rear Tyre: | 170/60 R17 |
| Wheel castor: | 99.6 mm / 3.9 in |
| Steering Head Angle: | 64.5 ° |
| Dimensions: | Height 1450 mm / 57.1 in Width 953 mm / 37.5 in Length 2210 mm / 87.0 in |
| Wheelbase: | 1507 mm / 59.3 in |
| Seat Height: | 890 mm - 910 mm / 35.0 in - 35.8 in |
| Dry Weight: | 220 kg / 485 lbs |
| Wet Weight: | 260 kg / 573 lbs |
| Fuel Capacity: | 30 Litres / 7.9 US gal |
| Reserve: | 4 Litres / 1.1 US gal |
