BMW R 12 Cruiser (2024) technical specifications

BMW R 12 Cruiser is produced in 2024. Engine is Four stroke, two cylinder horizontally opposed Boxer, two camshafts and four radially aligned valves per cylinder, central counter balancer shaft., displacement 1170 cc / 71.4 cub in , produces power 70.1 kW / 95 hp @ 6500 rpm and 106 Nm / 81 lb-ft @ 6000 rpm. BMW R 12 Cruiser wet weight is 227 kg / 500 lbs. BMW R 12 Cruiser has 6 photos.

Technical specifications

+ Add to 'Compare list'

Model:	R 12 Cruiser
Years:	2024
Engine:	Four stroke, two cylinder horizontally opposed Boxer, two camshafts and four radially aligned valves per cylinder, central counter balancer shaft.
Capacity:	1170 cc / 71.4 cub in
Bore x Stroke:	101 x 73 mm
Compression Ratio:	12:1
Cooling System:	Air/oil cooled
Lubrication:	Wet sump
Induction:	Electronic intake pipe injection / digital engine management system: BMS-O with throttle-by-wire
Emission:	Controlled 3-way catalytic converter, exhaust emission standards EU-59
Fuel:	Unleaded super (premium), octane number 95-98 (RON) (rated output at 98 RON)
Starting:	Electric
Max Power:	70.1 kW / 95 hp @ 6500 rpm
Max Torque:	106 Nm / 81 lb-ft @ 6000 rpm
Clutch:	Single dry plate clutch, hydraulically operated
Transmission:	6-speed, claw-shifted transmission with separate transmission housing
Primary Ratio:	1.737
Gear Ratios:	1st = 2.375, 2nd = 1.696, 3rd = 1.296, 4th = 1.065, 5th = 0.939, 6th = 0.848
Final Drive:	Shaft
Transmission Ratio:	2.910
Frame:	Four-part frame concept with front frame and three-part rear frame, load-bearing engine-gearbox unit, rear-seat frame removeable for one-up riding
Front Suspension:	46 mm upside-down telescopic forks
Front Wheel Travel:	90 mm / 3.5 in
Rear Suspension:	Cast aluminium single swinging arm with BMW Motorrad Paralever; central spring strut, spring preload fully adjustable by hook wrench, adjustable rebound-stage damping
Rear Wheel Travel:	90 mm / 3.5 in
Front Brakes:	Twin disc brake, floating brake discs, diameter 310 mm, 4-piston Monobloc radial brake caliper
Rear Brakes:	Single 265 mm disc, 2 piston floating caliper
ABS System:	BMW Motorrad ABS Pro
Wheels:	Aluminium cast wheels
Front Rim:	2.75 x 19
Rear Rim:	4.00 x 16
Front Tyre:	100/90 - R19
Rear Tyre:	150/80 - R16
Rake:	29.3 ?
Trail:	132 mm / 5.2 in
Dimensions:	Length 2200 mm / 86.6 in Width 830 mm / 32.7 in Height 1110 mm / 43.7 in
Wheelbase:	1519 mm / 59.8 in
Seat Height:	754 mm / 29.7 in
Inner leg curve:	1760 mm / 69.3 in
Wet Weight:	227 kg / 500 lbs
Fuel Capacity:	14 Litres / 3.7 US gal
