BMW R 1150RS (2002-03) technical specifications

BMW R 1150RS is produced in 2002-03. Engine is Four stroke, two cylinder horizontally opposed Boxer, 4 valves per cylinder, displacement 1130 cc / 69 cu in , produces power 70 kW / 95 hp @ 7250 rpm and 98 Nm / 19.0 kgf-m / 72.3 ft-lb @ 5500 rpm. BMW R 1150RS top speed is 212 km/h / 132 mph. BMW R 1150RS weighs 246 kg / 542.3 lbs. BMW R 1150RS has 4 photos.

Technical specifications

+ Add to 'Compare list'

Model:	R 1150RS
Years:	2002-03
Engine:	Four stroke, two cylinder horizontally opposed Boxer, 4 valves per cylinder
Capacity:	1130 cc / 69 cu in
Bore x Stroke:	101 x 70.5 mm
Cooling System:	Air/Oil cooled
Compression Ratio:	11.3:1
Lubrication:	Wet sump
Induction:	Bosch Motronic MA 2.4 Fuel injection
Ignition:	Electronic ignition MA 2.2 Bosch Motronic
Starting:	Electric
Max Power:	70 kW / 95 hp @ 7250 rpm
Max Torque:	98 Nm / 19.0 kgf-m / 72.3 ft-lb @ 5500 rpm
Clutch:	Dry, single plate, hydraulic operated
Transmission:	6 Speed
Final Drive:	Shaft
Frame:	Three section composite frame consisting of front & rear section, load bearing engine
Front Suspension:	Telelever with central suspension strut, continuously variable rebound stage.
Font Wheel Travel:	120 mm / 4.7 in
Rear Suspension:	Central suspension strut with coil spring and single tube gas shock absorber, continuously variable rebound stage, hydraulically adjustable spring preload.
Rear Wheel Travel:	135 mm / 5.3 in
Front Brakes:	2 x 305 mm Discs, 4 piston calipers
Rear Brakes:	Single 285 mm disc, 2 piston caliper
Front Tyre:	120/70 ZR17
Rear Tyre:	170/60 ZR17
Rake:	25.5°
Trail:	111 mm / 4.4 in
Dimensions:	Length 2170 mm / 85.4 in Width 920 mm / 28.3 in Height 1286 mm / 50.6 in
Wheelbase:	1473 mm / 58.0 in
Seat Height:	790 mm / 31.1 in 830 mm / 32.7 in
Dry Weight:	246 kg / 542.3 lbs
Fuel Capacity:	23 Litres / 6.1 US gal
Consumption Average:	4.8 L/100 km./ 21 km/l / 49.4 US mpg
Standing ¼ Mile:	12.4 sec
Top Speed:	212 km/h / 132 mph
