BMW R 1150GS (2002) technical specifications

BMW R 1150GS is produced in 2002. Engine is Four stroke, two cylinder horizontally opposed Boxer, 4 valves per cylinder, displacement 1130 cc / 69 cu in , produces power 62.5 kW / 85 hp @ 6750 rpm (rear tyre 58.9 kW / 79 hp @ 6750 rpm) and 98 Nm / 10.0 kgf-m / 71 lb-ft @ 5250 rpm. BMW R 1150GS top speed is 193.1 km/h / 120 mph. BMW R 1150GS weighs 228 kg / 503 lbs. BMW R 1150GS has 5 photos.

Technical specifications

+ Add to 'Compare list'

Model:	R 1150GS
Years:	2002
Engine:	Four stroke, two cylinder horizontally opposed Boxer, 4 valves per cylinder
Capacity:	1130 cc / 69 cu in
Bore x Stroke:	101 x 70.5 mm
Cooling System:	Air/Oil cooled
Compression Ratio:	10.3:1
Lubrication:	Wet sump
Induction:	Bosch Motronic MA 2.4 Fuel injection
Ignition:	Electronic ignition MA 2.2 Bosch Motronic
Starting:	Electric
Max Power:	62.5 kW / 85 hp @ 6750 rpm (rear tyre 58.9 kW / 79 hp @ 6750 rpm)
Max Torque:	98 Nm / 10.0 kgf-m / 71 lb-ft @ 5250 rpm
Clutch:	Single disc dry clutch, hydraulically operated
Transmission:	6 Speed
Final Drive:	Shaft
Gear Ratios:	1st 2.375 / 2nd 1.600 / 3rd 1.267 / 4th 1.038 / 5th 0.900 / 6th 0.800
Frame:	Three section composite frame consisting of front & rear section, load bearing engine
Front Suspension:	Light. Telelever with central spring strut, progressive coil spring, twin-tube gas-filled shock,
Front Wheel Travel:	210 mm / 8.2 in
Rear Suspension:	Patented BMW Paralever swing arm & shaft drive, single shock with variable rebound and damping adjustments
Rear Wheel Travel:	220 mm / 8.6 in
Front Brakes:	2 x 304mm discs, 4 piston calipers
Rear Brakes:	Single 276mm disc, 2 piston caliper
Wheels:	Cross spoke wheels
Front Wheel:	2.50 x 19
Rear Wheel:	4.00 x 17
Front Tyre:	110/80 R19
Rear Tyre:	150/70 R17
Rake:	26.2°
Trail:	121 mm / 4.8 in
Dimensions:	Length 2,180 mm / 85.8 in Width 980 mm / 38.6 in Height 1,435 mm / 56.5 in
Wheelbase:	1,501 mm / 59.1 in
Seat Height:	850 mm / 33.5 in
Dry Weight:	228 kg / 503 lbs
Wet Weight:	249 kg / 549 lbs
Fuel Capacity:	22 Litres / 5.8 US gal
Consumption Average:	5.7 L/100 km / 17.5 km/l / 41.2 US mpg
Standing ¼ Mile:	13.3 sec / 160.8 km/h / 99.9 mph
Top Speed:	193.1 km/h / 120 mph
