Technical specifications
|
| Model: |
G 650GS Sertao |
| Years: |
2013 |
|
Engine:
|
Four stroke, single cylinder, DOHC, 4 valves per cylinder
|
|
Capacity:
|
652 cc / 39.8 cub. in.
|
|
Bore x Stroke:
|
100 x 83mm
|
|
Compression Ratio:
|
11.5:1
|
|
Cooling System:
|
Liquid cooled
|
|
Induction:
|
Fuel induction
|
|
Ignition:
|
Capacitor Discharge Ignition system
|
|
Starting:
|
Electric
|
|
Max Power:
|
37 kW / 48 hp @ 6500 rpm
|
|
Max Torque:
|
60 Nm / 6.1 kgf-m / 44.25 lb-ft. @ 5000 rpm
|
|
Transmission:
|
5 Speed
|
|
Final Drive:
|
Chain
|
|
Frame:
|
Bridge-type steel section frame with bolted-on rear section
|
|
Front Suspension:
|
∅41mm telescopic fork with stabilizer bridge
|
|
Front Wheel Travel:
|
210 mm / 8.3 in
|
|
Rear Suspension:
|
Spring setting and rebound stage damping continuously adjustable,
|
|
Rear Wheel Travel:
|
210 mm / 8.3 in
|
|
Front Brakes:
|
Single ∅300mm disc, 2 piston caliper
|
|
Rear Brakes:
|
Single ∅240mm disc, 1 piston caliper
|
|
Wheels:
|
Wire spoke wheels
|
|
Rim, Font:
|
1.60 x 21"
|
|
Rim, Rear:
|
3.00 x 17"
|
|
Front Tyre:
|
90/90 S21
|
|
Rear Tyre:
|
130/80-17
|
|
Castor:
|
123 mm / 4.8 in
|
|
Steering Head Angle:
|
61.9°
|
|
Dimensions:
|
Length: 2185 mm / 86 in. Width: 920 mm / 36.2 in. (incl. mirrors) Height: 1440 mm / 56.7 in.(excl. mirrors)
|
|
Wheelbsase:
|
1484 mm / 58.4 in.
|
|
Seat Height:
|
860 mm to 900 mm / 33.9 in. to 35.4 in.
|
|
Dry Weight:
|
176 kg / 388 lbs.
|
|
Wet-Weight:
|
191 kg / 421 lbs
|
|
Fuel Capacity:
|
17.3 Litres / 4.6 US gal.
|
