BMW F 900XR (2025) technical specifications

BMW F 900XR technical specifications

BMW F 900XR is produced in 2025. Engine is Four stroke, parallel twin cylinder, DOHC, 4 valves per cylinder, displacement 895 cc / 54.6 cu-in , produces power 78 kW / 105 hp @ 8500 rpm and 93 Nm / 68.6 lb-ft @ 6750 rpm. BMW F 900XR wet weight is 216 kg / 476 lbs. BMW F 900XR has 6 photos.

Technical specifications

+ Add to 'Compare list'
Model: F 900XR
Years: 2025
Engine: Four stroke, parallel twin cylinder, DOHC, 4 valves per cylinder
Capacity: 895 cc / 54.6 cu-in
Bore x Stroke: 86 x 77 mm
Compression Ratio: 13.1:1
Cooling System: Liquid cooled
Emission: Closed-loop 3-way catalytic converter, emission standard EURO5+
Induction: Electronic intake pipe injection / digital engine management system: BMS-X with throttle-by-wire
Ignition: Electronic
Alternator: permanent magnetic alternator 416 W (nominal power)
Battery: 12 V / 9 Ah, maintenance-free
Starting: Electric
Max Power: 78 kW / 105 hp @ 8500 rpm
Max Torque: 93 Nm / 68.6 lb-ft @ 6750 rpm
Clutch: Multiple-disc wet clutch (anti hopping), mechanically operated
Transmission: Constant mesh 6-speed gearbox integrated in crankcase
Final Drive: Endless O-ring chain with shock damping in rear wheel hub
Frame: Bridge-type frame, steel shell construction, load bearing engine
Front Suspension: 43mm inverted fork with adjustable damping rebound and compression damping as well as adjustable spring preload.
Front Wheel Travel: 170 mm / 6.7 in
Rear Suspension: Aluminum double-sided swing arm, directly linked central spring strut, hydraulically adjustable spring preload, adjustable rebound damping (Optional equipment: Dynamic ESA)
Rear Wheel Travel: 173 mm / 6.8 in
Front Brakes: 2 x 320mm floating discs, 4-piston radial brake calipers, hydraulically operated
Rear Brakes: Single 265mm discs, single-piston floating caliper, hydraulically operated
ABS System: BMW Motorrad ABS Pro
Wheels: Cast aluminium wheels
Front Wheel: 3.50″ x 17″
Rear Wheel: 5.50″ x 17?
Front Tyre: 120/70 ZR 17
Rear Tyre: 180/55 ZR 17
Rake: 28?
Trail: 119.4 mm / 4.1 in
Dimensions: Length 2159 mm / 85 in Width 919 mm / 36.2 in
Wheelbase: 1534 mm / 60.4 in
Seat Height: 846 mm / 33.3
Wet Weight: 216 kg / 476 lbs
Fuel Capacity: 15.5 Litres / 4.1 US gal
