Beta RS 350 (2014) technical specifications
Beta RS 350 is produced in 2014. Engine is Four stroke, single cylinder, displacement 349 cc / 21.3 cu in Beta RS 350 weighs 108 kg / 240 lbs. Beta RS 350 has 1 photos.
Technical specifications
+ Add to 'Compare list'| Model: | RS 350 |
| Years: | 2014 |
| Engine: | Four stroke, single cylinder |
| Capacity: | 349 cc / 21.3 cu in |
| Bore x Stroke: | 88 x 57.4 mm |
| Cooling System: | Liquid cooled |
| Compression Ratio: | 12.1:1 |
| Induction: | Keihin FCR-MX Ø 39 mm |
| Lubrication: | Twin oil pumps with cartridge oil filter. Separate oil for engine and clutch |
| Engine Oil Capacity: | 0.8 L / 0.2 US gal |
| Ignition: | DC-CDI with variable ignition timing, Kokusan. |
| Spark Pluc: | NGK LKAR 8A-9 |
| Starting: | Electric and kick |
| Spark Plug: | NGK LKAR 8A-9 |
| Clutch: | Wet multi-disc |
| Gearbox Oil Capacity: | 0.8 L / 0.2 US gal |
| Transmission: | 6 Speed |
| Final Drive: | O-ring chain, DID |
| Primary Ratio: | 31:73 |
| Final Ratio: | 14:45 |
| Frame: | Molybdenum steel with double cradle split above exhaust port. Air filter access from the side |
| Front Suspension: | Marzocchi USD fork, Ø 45 mm, adjustable compression and rebound, TFX technology |
| Front Wheel Travel: | 290 mm / 11.4 in |
| Rear Suspension: | Sachs shock w/adjustable rebound and hi/low speed compression |
| Rear Wheel Travel: | 290 mm / 11.4 in |
| Front Brakes: | Single Ø 260 mm floating disc, 2 piston caliper |
| Rear Brakes: | Single Ø 240 mm disc, 1 piston caliper |
| Front Tyre: | 90/90 -21 |
| Rear Tyre: | 140/80 -18 |
| Wheelbase: | 1475 mm / 58.1 in |
| Ground Clearance: | 320 mm / 12.6 in |
| Seat Height: | 934.7 mm / 36.8 in |
| Footrest Height: | 411 mm / 16.2 in |
| Dry Weight: | 108 kg / 240 lbs |
| Fuel Capacity: | 7.9 L / 2.1 US gal |
