Benelli TNT 1130 Naked (2004) technical specifications
Benelli TNT 1130 Naked is produced in 2004. Engine is Four stroke, transverse three cylinder, DOHC, 4 valves per cylinder, displacement 1130 cc / 69 cu in , produces power 101 kW / 135 hp @ 9500 rpm and 110 Nm / 11.2 kgf-m / 81.1 lb-ft @ 7750 rpm. Benelli TNT 1130 Naked top speed is 243 km/h / 151 mph. Benelli TNT 1130 Naked weighs 205 kg / 452 lbs. Benelli TNT 1130 Naked has 4 photos.
Technical specifications
+ Add to 'Compare list'Model: | TNT 1130 Naked |
Years: | 2004 |
Engine: | Four stroke, transverse three cylinder, DOHC, 4 valves per cylinder |
Capacity: | 1130 cc / 69 cu in |
Bore x Stroke: | 88 x 62 mm |
Compression Ratio: | 11.5:1 |
Cooling System: | Liquid cooled |
Lubrication: | Wet sump |
Oil: | API SJ 15W/50 - synthetic |
Oil Capacity: | 4 L / 1.1 US gal |
Induction: | Electronic injection with 1 injector per cylinder |
Ignition: | Electronic |
Battery: | 12V, 10Ah |
Starting: | Electric |
Max Power: | 101 kW / 135 hp @ 9500 rpm |
Max Torque: | 110 Nm / 11.2 kgf-m / 81.1 lb-ft @ 7750 rpm |
Clutch: | Oil bath |
Transmission: | 6 Speed |
Final Drive: | Chain |
Gear Ratios: | 1st 2.786 / 2nd 1.994 / 3rd 1.524 / 4th 1.304 / 5th 1.167 / 6th 0.926 |
Frame: | Front ASD steel tube trellis, fastened with drawer screws to boxed rear section, aluminium alloy castings. |
Rake: | 23.5° |
Trail: | 100 mm / 3.9 in |
Front Suspension: | Marzocchi 50 mm diameter upside down fork ASD steel tube trellis oscillating main fork |
Front Wheel Travel: | 120 mm / 4.7 in |
Rear Suspension: | Mono shock absorber with adjustable extension and spring load |
Rear Wheel Travel: | 115 mm / 4.5 in |
Front Brakes: | 2 x 320 mm Ø discs, 4 piston calipers |
Rear Brakes: | Single 240 mm Ø disc, 2 piston caliper |
Wheels: | Aluminium alloy, 5-spoke |
Front Rim: | 3.5 x 17 in |
Front Tyre: | 120/70-ZR17 (58W) |
Rear Rim: | 6.0 x 17 in |
Rear Tyre: | 190/55-ZR17 (73W) |
Dimensions: | Length: 2100 mm / 82.7 in Width: 900 mm / 35.4 in Height: 1050 mm / 41.3 in |
Wheelbase: | 1443 mm / 56.8 in |
Seat Height: | 780 mm / 30.7 in |
Dry Weight: | 205 kg / 452 lbs |
Wet Weight: | 215 kg / 474 lbs |
Gross Vehicle Weight Rating: | 400 kg / 882 lbs |
Fuel Capacity: | 16.5 L / 4.4 US gal |
Fuel Reserve: | 5 L / 1.3 US gal |
Consumption Average: | 5.8 L/100 km / 17.2 km/lit / 40.5 US mpg |
Standing ¼ Mile: | 11.0 sec |
Top Speed: | 243 km/h / 151 mph |
Colours: | Yellow, Red, Black, Green/silver |
