Technical specifications
|
| Model: |
BKX 250 |
| Years: |
2023 |
|
Engine:
|
Four stroke, single cylinder, DOHC, 4 valves
|
|
Capacity:
|
249.2 cc / 15.2 cu in
|
|
Bore x Stroke:
|
72 x 61.2 mm
|
|
Cooling System:
|
Liquid cooled
|
|
Compression Ratio:
|
11.2:1
|
|
Lubrication:
|
Forced wet sump
|
|
Exhaust:
|
With catalytic converters and oxygen sensor
|
|
Emission:
|
Euro 5
|
|
Induction:
|
Electronic fuel injection with 37mm Ø throttle body
|
|
Ignition:
|
Delphi MT05.03
|
|
Starting:
|
Electric
|
|
Max Power:
|
19 kW / 25.8 hp @ 9250 rpm
|
|
Max Torque:
|
21.1 Nm / 15.5 lb-ft @ 8000 rpm
|
|
Clutch:
|
Wet
|
|
Transmission:
|
6 Speed
|
|
Final Drive:
|
Chain
|
|
Frame:
|
Trellis frame in steel tubes
|
|
Front Suspension:
|
41 mm Upside down telescopic forks
|
|
Front Wheel Travel:
|
180 mm / 7.0 in
|
|
Rear Suspension:
|
Rear swing arm in steel, shock absorber with progressive link, adjustable in spring preload
|
|
Rear Wheel Travel:
|
180 mm / 7.0 in
|
|
Front Brakes:
|
Single 280 mm disc, 4-piston caliper
|
|
Rear Brakes:
|
Single 240 mm disc, 1-piston caliper
|
|
ABS:
|
Standard
|
|
Wheels:
|
Spoked wheel with Aluminum hub and rim
|
|
Front Rim:
|
2.15 x 19
|
|
Rear Rim:
|
2.5 x 17
|
|
Front Tyre:
|
100/90 - R19 M/C 57V M+S
|
|
Rear Tyre:
|
140/80 - R17 M/C 65V M+S
|
|
Dimensions:
|
Length: 2068 mm / 81.4 in Width: 970 mm / 38.1 in Height: 1215 mm / 47.8 in
|
|
Wheelbase:
|
1432 mm / 56.3 in
|
|
Ground Clearance:
|
220 mm / 8.6 in
|
|
Seat Height:
|
835 mm / 32.8 in
|
|
Wet Weight:
|
165 kg / 363.7 lbs
|
|
Fuel Capacity:
|
13.5 Litres / 3.5 US gal
|
