Technical specifications
|
| Model: |
4F Square Four 600 |
| Years: |
1932-36 |
|
Production:
|
2647 units
|
|
Engine:
|
Four stroke, parallel twin, OHC
|
|
Capacity:
|
601 cc / 36.7 cu in
|
|
Bore x Stroke:
|
56 x 61 mm
|
|
Cooling System:
|
Air cooled
|
|
Compression Ratio:
|
6.9:1
|
|
Exhaust:
|
2 x 1-into-1
|
|
Induction:
|
Carburetor
|
|
Starting:
|
Kick start
|
|
Max Power:
|
17 kW / 23 hp @ 5600 rpm (1939 model)
|
|
Transmission:
|
4-Speed, Burman
|
|
Final Drive:
|
Chain
|
|
Frame:
|
Brazed-lug tubular semi-cradle construction, duplex down-tube
|
|
Front Suspension:
|
Ariel centre spring girders
|
|
Rear Suspension:
|
Rigid, spring loaded saddle
|
|
Front Brakes:
|
Drum, 7 in
|
|
Rear Brakes:
|
Drum, 7 in
|
|
Wheels:
|
Steel, laced wire spokes
|
|
Front Rim:
|
3.25 x 19
|
|
Rear Rim:
|
3.25 x 19
|
|
Wheelbase:
|
1384mm / 54.5 in
|
|
Dry Weight:
|
168 kg / 370 lbs
|
