Technical specifications
|
| Model: |
SX 50 |
| Years: |
2013 |
|
Engine:
|
Single cylinder, two stroke
|
|
Capacity:
|
49.9 cc / 3.04 cu in
|
|
Bore x Stroke:
|
39.9 x 40 mm
|
|
Cooling System:
|
Liquid cooled
|
|
Compression Ratio:
|
11.5:1
|
|
Lubrication:
|
Automatic mixer
|
|
Exhaust:
|
Single, hich under seat
|
|
Induction:
|
Dell'Orto PVHA 17.5 carburetor
|
|
Ignition:
|
Electronic CDI
|
|
Starting:
|
Kick
|
|
Clutch:
|
Wet, multi plate
|
|
Transmission:
|
6 speed
|
|
Gear Ratios:
|
1st 11:34 / 2nd 15:30 / 3rd 18:27 / 4th 20:24 / 5th 22:23 / 6th 23:22
|
|
Final Drive:
|
Chain
|
|
Primary Drive Ratio:
|
21/87
|
|
Final Drive Ratio:
|
11/53
|
|
Frame:
|
Steel beam
|
|
Front Suspension:
|
Hydraulic fork, Ø 40 mm
|
|
Front Wheel Travel:
|
195 mm / 7.7 in
|
|
Rear Suspension:
|
High strength steel swingarm, hydraulic monoshock
|
|
Rear Wheel Travel:
|
180 mm / 7.1 in
|
|
Front Brakes:
|
Single stainless steel disc, Ø 260 mm, floating caliper
|
|
Rear Brakes:
|
Single disc, Ø 180 mm, floating caliper
|
|
Wheels:
|
Aluminium and alloy rims and spokes
|
|
Front Tyre:
|
100/80 ZR17
|
|
Rear Tyre:
|
130/70 ZR17
|
|
Dimensions:
|
Length: 2045 mm / 80.5 in Width: 835 mm / 32.5 in
|
|
Wheelbase:
|
1400 mm / 55.1 in
|
|
Seat Height:
|
835 mm / 32.9 in
|
|
Dry Weight:
|
98 kg / 216 lbs
|
|
Fuel Capacity:
|
7 L / 1.85 US gal
|
