Technical specifications
|
| Model: |
Model 30 600 |
| Years: |
1956 |
|
Engine:
|
Four stroke, pushrod parallel twin, OHV, 2 valves per cylinder,
|
|
Capacity:
|
593 cc / 36.2 cu in
|
|
Bore x Stroke:
|
72 x 72.8 mm
|
|
Compression Ratio:
|
7.0 : 1
|
|
Cooling System:
|
Air cooled
|
|
Induction:
|
Carburetor
|
|
Ignition:
|
6 Volt Magnet (Lucas K2F)
|
|
Starting:
|
Kick
|
|
Clutch:
|
Multi Plate (dry, Burman)
|
|
Max Power:
|
24.6 kW / 33 hp @ 6800rpm
|
|
Transmission:
|
4 Speed
|
|
Drive:
|
Chain
|
|
Frame:
|
Single cradle
|
|
Front Suspension:
|
Hydraulic telescopic fork
|
|
Rear Suspension:
|
Dual chocks
|
|
Front Brakes:
|
Drum
|
|
Rear Brakes:
|
Drum
|
|
Front Tyre:
|
3.25 -19
|
|
Rear Tyre:
|
3.50 -19
|
|
Weight:
|
178 kg / 396 lbs
|
|
Fuel Capacity:
|
16 L / 4.2 US gal
|
|
Top Speed:
|
95mph / 152 kph
|
